10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing

MOQ: 1
Standard Packaging: Full package for sea transportation
Delivery Period: according to contract
Payment Method: L/C,T/T
Supply Capacity: 200 SETS
Detail Information
Product Description
Detail Information
Brand Name
APEX
Certification
CE
Model Number
DRSZ420 /508/350/678
Capacity:
1-25TH
Application:
Poultry & Livestock Feed Processing
Roller Assembly:
2 Rollers
Type:
SZLH Animal Feed Pellet Mill
Animal Pellet Size:
2mm-10mm
HS Code:
8436100000
Highlight:

6mm Animal Feed Pellet Mill Machine

,

4mm Animal Feed Pellet Mill Machine

,

Pig Ring Die Animal Feed Pellet

Product Description
SZHL508 Animal Feed Pellet Mill Machine
The SZHL508 Pig Chicken Animal Feed Pellet Mill Machine is a high-capacity ring die feed production system designed for manufacturing various animal feeds including livestock, poultry, ruminant, and aquatic feeds. This industrial-grade machine produces pellets in sizes of 2mm, 4mm, and 6mm to meet diverse feeding requirements.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 0
Available in capacities ranging from 1T/H to 40T/H, these pellet mills feature core components constructed from stainless steel and special alloy steel, ensuring exceptional durability and corrosion resistance for long-term industrial operation.
Animal Feed Pellet Mill Models & Specifications
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 1
Model Main Motor Dia. of Ring Die Pellet Size Capacity
SZHL250 22 Kw 250mm 2-12mm 1-2 T/H
SZHL320 37 Kw 320mm 2-12mm 3-4 T/H
SZHL350 55 Kw 350mm 2-12mm 5-7 T/H
SZHL420 110 Kw 420mm 2-12mm 8-12 T/H
SZHL508 160 Kw 508mm 2-12mm 10-18 T/H
SZHL678 220/250 Kw 678mm 2-12mm 20-30 T/H
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 2
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 3
Customized Feed Production Line Process
1. Raw Material Receiving and Cleaning
Bulk raw materials including corn and soybean meal undergo thorough inspection and cleaning processes. Impurities are removed using specialized equipment, followed by transportation to storage silos via receiving and demagnetization systems.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 4
2. Batching Process
Raw materials are precisely weighed according to formula requirements using automated batching scales. Materials are transported from batching bins to powder storage bins, with manual addition of small quantities and premixes to ensure accurate product formulation.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 5
3. Grinding Process
Raw materials from storage silos are processed through crushers to create fine powder, which is then conveyed to mixing silos for subsequent processing stages.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 6
4. Mixing Process
Various crushed raw materials are discharged into industrial mixers from the mixing chamber. Liquid additives, including oils, are incorporated through automated systems to achieve uniform mixture consistency and nutritional balance.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 7
5. Pelleting Processing
Processed raw materials are fed into the pellet machine, with optional conditioners installed to meet specific production requirements and optimize pellet quality.
10T/H Capacity SZLH Feed Pellet Mill with 2-10mm Pellet Size and Ring Die Design for Animal Feed Processing 8
6. Packing Processing
Final pellet products are packaged using automated systems to ensure proper storage, handling, and distribution.
Frequently Asked Questions
Will you help with installation and staff training?
Yes, we provide comprehensive support including skilled engineers for installation, commissioning, and complete operator training services.
How do you control the quality?
We maintain strict quality control throughout the manufacturing process, backed by our "Quality is life" philosophy. All products come with a one-year warranty and are certified with CE, BV, and SGS standards.
Can you provide turn-key project?
Yes, we have extensive experience in delivering complete turn-key projects for international clients.
Where is your factory located? How can I visit there?
Our factory is located in Liyang City, Jiangsu Province, China, with convenient access from Shanghai and Nanjing airports. We warmly welcome all domestic and international clients for factory visits.
When can I get the price?
We typically provide quotations within 24 hours of receiving your inquiry. For urgent pricing requests, please contact us directly by phone or indicate priority in your email.
