HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang
  • name
  • name

HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang

MOQ: 2pcs
Price: Negotiable
Standard Packaging: Plywood cases or iron case is be used . the complete machine is packed by plastic ,all siutable for sea transportation
Delivery Period: 15 working times
Payment Method: T/T, L/C
Supply Capacity: 100-150 pcs per month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
APEX BIOMASS
Model Number
muyang
Items:
Pellet Machine Roller Shall
Name:
Roller Shell For Pellet Mill Muyang Pellet Rollers
Raw Material:
High Quality AS Steel
Heating Treament:
58-62
Application:
Muyang Feed Pellet Press
Others Parts:
Ring Die
Customized:
Accepted
Highlight:

HRC58 Pellet Machine Roller Shell

,

HRC62 Pellet Machine Roller Shell

,

grinding mill spare parts 508

Product Description

Roller Shell For Pellet Mill Muyang Pellet Rollers



Main technical paremeter of pressure roller shell :

  • Size indication: outer diameter / inner diameter X width
  • Surface processing type: through groove, closed groove, punching
  • Material: according to customer requirements
  • Hardness: HRC 58-62 according to diferent raw material

Roller shell, commonly known as pressure roller, is one of the main work parts in pellet machine and is applied for processing various kinds of biomass fuel pellet, animal feed pellet and other pellets. It is made of wear resistant alloy steel with carburization heat treatment, featuring even hardness and long service life.



Product Name Roller Shell For Pellet Mill Muyang Pellet Rollers
Raw Material 60Si2Mn,20CrMnTi,40Cr,X46Cr13,50#Alloy steel,42CrMo,Stainless Steel,etc( As customer demanded, not always used).
Certification ISO9001, SGS, ISO14001





Product Type



Roller for XGJ560,850 etc .

1.SZLH250,300,320,350,400,420,508,........
2.MU350,420,600,610M......
3.AHHC350,420......
4.MUZL150......
MUYANG,FAMSUN,ZHENGCHANG,CPM,HRZL,SDPM,KYM,CPP,Awila,

C600,TAIWANYIDA,TAIWANWANDEFU,400D,ZHENGCHENG,HDJ008......

Other Particular Dimension(L*W*H): Can be customrized.
Used feed animal press

HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang 0



We can make all kinds of pellet mill roller shells according to customers' drawing.
1. Grade: First level
2. Size:1.0~20.0 mm
3. Certification: CE ISO SGS



Note :

1. Correctly select the appropriate die hole compression ratio;

2. Correctly adjust the working gap between the ring die and the pressure roller to be between 0.1 and 0.3mm (the pressure roller is driven by the ring die after the new granulator is turned on in a “like rotating but not rotating” state);

3. The new ring die should be used with a new pressure roller, and the pressure roller and the ring die must be loose before and then tightened. When sharp corners appear on both sides of the pressure roller, the flange of the pressure roller should be smoothed with a hand grinder in time to facilitate a good fit between the pressure roller and the ring die;

4. The raw material must undergo preliminary cleaning and magnetic separation before the pelletizer to reduce iron pressing into the die hole. And to check the die hole regularly to see if there is any blockage. Punch out or drill out the blocked mold hole in time;









HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang 1



HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang 2

HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang 3HRC58 To 62 Pellet Machine Roller Shell Grinding Mill Spare Parts For Pellet Mill Muyang 4
