Paper Wood 6TPH 7TPH 132kw Hammer Mill Machine Water Drop Small Feed Grinder Mixer

Paper Mill Wood Crushing Hammer Mill Water Drop Type

Features

• Adopting steel plate welding structure, the hammer mill rotor and the motor are mounted on the same base, and the serpentine spring coupling is directly connected to the transmission, and the transmission efficiency is high;
• The base is welded with thick steel plate and reduces the center of gravity of the spindle to effectively improve the vibration phenomenon;
• The rotor is dynamically balanced to make the rotor work smoothly and can work in forward and reverse directions to extend the service life of the wearing part;
• The operation door has a safety interlock to ensure that the motor cannot be started when the operation door is opened, ensuring safety;
• Replace the bearing with a larger load. Effectively improve the temperature rise of the bearing. Effectively extend bearing life;
• Quick-open full-open mobile access door; (national patent)

Attractive advantages

• CNC processing, with high accuracy
• Special process of hammer, with long service time
• Siemens motor
• Reasonable price
• Non-dust workshop

This paper mill wood  hammer mill is applicable for the material after chipping (thickness≤10mm), and it should be fiber material with big moisture and oiliness and also applicable for coarse grinding.

Working principle is that the raw material go into the grinding room, then will be grinding by the impact force and shear force caused by high speed rotating rotor and collision force caused by the high speed rotating rotor, then pass through the screen to get the eligible products.

hammer mill always comes with cyclone, air lock, stean fan, and bag dust collector .

• Available raw material: wood chips ,wood bricks, shavings, straw, peanut shell, palm shell, cotton seed, bamboo dust, rice husk, elephant grass, sugar cane, pulp, olive dust, and so on.
• Applications: the hammer mill can be widely used in home made production and industrial production in the field of agricultural, wood and animal industry.

Note:The above indicators meet the following conditions, the variety of raw materials, wood chips, moisture is not more than 13%, and the capacity is not less than 0.72T/m3. The sieve diameter of the sieve plate of the pulverizer is Φ10, and the opening rate is not less than 33%. The sieve aperture/opening ratio affects throughput.
