5 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine

Place of Origin CHINA
Brand Name APEX BIOMASS
Certification CE SGS
Model Number KLF880
Minimum Order Quantity 1set
Price Negotiable
Packaging Details 2*KLF880 IN one 20GP . Plywood or metal case if spare parts
Delivery Time 30-35 working days
Payment Terms T/T, L/C
Supply Ability 5sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Items RDF Pellet Mill Name Paper Waste Pellet Mill Paperboard Pellet Press Machine
Application Paper Waste Pellet Press Paper Waste Includes Waste Means Newspapers, Magazines, Cardboard
Crushing Necessary Paper Waste Pellet Mill Model KLF880
Capacity 10t/h ,5-20t/h ,customized Pellet Water Content Under 15%
Highlight

5tph waste paper crushing machine apex

,

20tph waste paper crushing machine

,

Paper Paperboard biodegradable shredder machine

Leave a Message
Product Description

Paper Waste Pellet Mill Paperboard Pellet Press Machine



As we know, 90% of paper products are made from wood, and 43% of harvest wood are made into paper products. In this term, Paper recycling contributes to saving wood resources.And those wood waste  is kind of high caloric value most be made pellet in power plant ,electric generated ,heating centre . So make the paper waste into paper waste pellete is a good recycling way .



And Paper waste means newspapers, magazines, cardboard and any other form of paper which is free of contaminated matter and is capable of being recycled.



The introduction of paper waste pellet mill :

  • The pressure roller shaft has a built-in box, and no butter is required.
  • The whole oil cooling adopts a constant temperature plate cooling system, the oil temperature is constant, and the production is worry-free.
  • The double-turbo adjustment of the pressure roller is easy to operate and the adjustment is more accurate.
  • The oil temperature control system adopts automatic temperature control alarm.
  • High efficiency, energy saving, under the same power, the production capacity is increased by 30% compared with other models.
  • The double-layer design of the ring mold, one mold is dual-purpose, and the technology is environmentally friendly.
  • Wide range of material moisture (12%-25%)
  • The precision production of ring die and pressure roller can save 50-70% of the cost compared with other equipment. Without grease, it saves 3-5 usd in production costs compared to other equipment.
  • The equipment has low failure rate and extremely low maintenance cost.
  • Wide range of materials: waste ,sawdust, straw, bagasse, eucalyptus bark, peanut husk, rice husk, miscellaneous wood, bamboo, etc



The technical data :



Model KLF880
Dimension 4000*2000*2400
Main power 200kw
Ring Die size Inner 880mm
Support power 7.5kw
Pelletizig chamber no roller bearing in rollers
Running temperature ≤80℃
Roller adjust Manual
Weight 14ton
Running noise ≤80
Lubrcating method oil free
Cooling method Oil cooling
Output 3-4t/h
Running time 24hours





Paper  Pelletizing mill  is suitable to make  pellets with the diameters of 22mm, 24mm and 28mm, customers can use different diameters ring die to produce suitable pellets according to the actual requirements.





5 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 0



5 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 1



5 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 25 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 3

Application show :



5 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 45 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 55 To 20tph Paper Paperboard Waste Paper Crushing Machine Biodegradable Shredder Machine 6
