4t/H Tapioca Ring Die Pellet Mill Biomass Wood Pellet Machine
| Place of Origin | CHINA |
|---|---|
| Brand Name | APEX BIOMASS |
| Certification | CE SGS |
| Model Number | ABL508 |
| Minimum Order Quantity | 1set |
| Price | Negotiable |
| Packaging Details | 2 sets pellet mill machine *1 20gp . spare parts packed by plywood case or iron case only . |
| Delivery Time | 15 working times |
| Payment Terms | T/T, L/C |
| Supply Ability | 10 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Tapioca Pellet Making Machine 4t/h Ring Die Pellet Mill | Capacity | 3-4th |
|---|---|---|---|
| Motor | 110kw 6p | Ring Die Material | Alloy Steel Or Ss Steel |
| Total Weight | 3.3t | Voltge | 380v 50hz /customized |
| Spare Parts | Ring Die ,roller Shell ,five Piece Cover Etc | Ring Die Hole | 6-12mm |
| High Light | apex 4t/h ring die pellet mills,Tapioca ring die pellet mill,apex apex biomass wood pellet machines |
||
Product Description
Tapioca Pellet Making Machine 4t/h Ring Die Pellet Mill
Main technical parameters :
Model: APL508
Capacity : 3-4T/H
Power : 110KW 6P
Weight : about 3.3TON
▶ Pelletizing Chamber:
Provide space for pelletizing . The main components are roller assembly and ring die, bearing, chammer cover, etc.
Cutting handle is equipped to control the length of pellet so that can get as your needs .
Inspecting window on the pelletizing chamber to insepct he cutting of pellets by the cutter at any time, and control the production situation.
Waring : Pushing hand is forbbiden when the machine is running .
▶ Press Roller Assembly:
The roller assembly is made of 42CrMo material .Including roller shell ,five piece cover ,bearing , Circlip etc .
Roller shell and five piece cover is quick parts .
▶ The working priciple :
When the powders with different particle sizes are guided by the scraper in the pressing chamber into the pre-compression area between the actively rotating ring die and the driven rotating pressure roller, the material has a certain degree of looseness, and the material is squeezed by the ring die and the pressure roller so as to High density particles are formed.Pellet mill is divided into biomass and animal feed pellet machine according to different raw material .
▶ The Ring die
key part of tapioca pellet making machine which will influence the capacity of pellet machine and the quality of pellet .
● The ring die is made of 42CrMo,customzied raw material which is more wear-resistant and durable than ordinary alloy steel or carbon steel ring die.
● The special surface carburizing treatment increases the surface hardness of the ring die and significantly improves the service life.
● Compressed step release hole is adopted to ensure that the material enters the die hole smoothly.
FAQ
1. What is our payment term?
A: 30 % by TT in advance, 70% by TT before shippment;
B: 100% Confirmed, Irrevocable, LC at sight
2. Can I operate this production line alone?
According to the scale of pellet production line .2-3 larbors necessary to inspect the feeding , discharing etc .
3. Will you train me to do the maintanance .
Yes, while our engineers guide you to install and train you how to operate the sawdust pelelt machine and replace .
