Ring Die Wood Pelletizing Equipment PLC Control For Agriculture Waste
Place of Origin | CHANGZHOU ,CHINA |
---|---|
Brand Name | APEX |
Certification | CE/SGS |
Model Number | 508 |
Minimum Order Quantity | 1 sets |
Price | Negotiable/830usd |
Packaging Details | Packed by plastic film ,spare parts in plywood case or iron case only |
Delivery Time | 15 working days |
Payment Terms | L/C, T/T |
Supply Ability | 20 sets per month |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xWeight | 3.5t/9.5ton | Material | Stainless Steel |
---|---|---|---|
Product Name | Biomass Pellet Mill Machine | Control System | PLC |
Speed Of Main Shaft | 1420r/min | Power | 90kw /132kw/200kw |
Lubrication System | Manual Or Auto | Feeder Power | 0.75kw |
Highlight | PLC Wood Pelletizing Equipment,Agriculture Waste Wood Pelletizing Equipment,1420r/min Biomass Pellet Mill Machine |
Product Description:
The Biomass Pellet Mill Machine is a wood pelletizing equipment that is designed to process biomass materials into biomass pellets for biofuel. This pelletizing mill machine is equipped with a force feeding power of 3kw, a feeder power of 0.75kw, a PLC control system, and a voltage of 380V. The speed of the main shaft can reach 1420r/min, making it an ideal choice for biomass wood pellet production. With high efficiency and user-friendly operation, this pelletizing mill machine is a reliable and cost-effective solution for biomass wood pelletizing.

Features:
Processing machine is :
1 Korea DOOSAN Large Processing Center
2 transmission parts heat treatment workshop
3 large ring die forging center
4 Germany NILES gear grinding machine
5LGMazak Little Giant CNC Turning Center
6 Samsung Turning Center PL35M
7.The whole reduceing box warranty for 2 years
Technical Parameters:
Parameter | Value |
---|---|
Product Name | Biomass Pellet Mill Machine |
Raw Material Application | Biomass Waste Such As Wood, Agriculture Waste |
Material | Stainless Steel |
Voltage | 380V |
Speed of Main Shaft | 1420r/min |
Roller Quantity | 2 Pcs |
Power | 90kw /132kw/200kw |
Feeder Power | 0.75kw |
Force Feeding Power | 3kw |
Warranty | 1 Year |
Bomass pellet mill machine | |||
![]() |
Model :420,508 ,650 | ||
Model DR420 | |||
Capacity :1-1.5t/h | |||
Power :90kw | |||
Weight :3200kg | |||
Dimension :2500*1100*1600mm | |||
Model :DR508 | |||
Capacity :1.5-2t/h | |||
Power :132kw | |||
Weight 5300 | |||
Dimension :2800*1500*2500mm | |||
Model :650 | |||
Capacity :2.5-3t/h | |||
Power :200kw | |||
Ring die :Customized alloy steel or 4Cr13 | Weight 9500kg | ||
Dimension 3530*1580*2400mm |
Applications:
APEX Biomass Pellet Mill Machine is perfect for pelletizing biomass materials, such as wood, agricultural waste, etc. The machine has a PLC control system, which helps it to produce high-quality biomass pellets. The force feeding power of 3kw makes it easier to pelletize, and the stainless steel material increases its durability. The machine is also backed by a 1-year warranty, making it a reliable choice for pelletizing biomass materials.
APEX Biomass Pellet Mill Machine is the ideal choice for customers who are looking for a reliable and efficient way to pelletize biomass materials. With its PLC control system and stainless steel material, customers can enjoy a better pelletizing experience. The machine also comes with a 1-year warranty, making it a cost-effective choice. So, if you're looking for a reliable and efficient way to pelletize biomass materials, then APEX Biomass Pellet Mill Machine is the perfect choice for you.

Customization:
We can customize each part of biomass pellet machine for you .
Support and Services:
We provide technical support and service for Biomass Pellet Mill Machine.
- We provide 24/7 customer service and technical support to ensure fast and efficient delivery of spare parts and services.
- We provide professional on-site installation, commissioning, maintenance and training services.
- We provide timely and accurate parts and accessories to ensure the safe and efficient operation of the Biomass Pellet Mill Machine.
- We provide technical advice on the operation and repair of the Biomass Pellet Mill Machine.
Packing and Shipping:
Packaging and Shipping for Biomass Pellet Mill Machine:
The Biomass Pellet Mill Machine is packed and shipped in an appropriate crate with all the necessary protective materials to ensure its safe arrival to the customer. The crate is then secured onto a pallet for easy loading and unloading from the truck. All shipments will be tracked and monitored for their safety and timely arrival.

FAQ:
Brand Name: APEX
Place of Origin: CHANGZHOU , CHINA
Q&A
Q1: What is the size of the Biomass Pellet Mill Machine?
A1: The Biomass Pellet Mill Machine from APEX has a dimension of 2200×1400×1900mm (L×W×H).
Q2: What type of materials can be processed by Biomass Pellet Mill Machine?
A2: The Biomass Pellet Mill Machine from APEX is capable of processing a wide range of materials such as wood, straw, grass, etc.
Q3: What is the power of the Biomass Pellet Mill Machine?
A3: The Biomass Pellet Mill Machine from APEX has a power of 90KW.132KW.200KW
Q4: What is the capacity of the Biomass Pellet Mill Machine?
A4: The Biomass Pellet Mill Machine from APEX has a capacity of 1-20TPH.
