Wood Pallet Crusher 20t/h Heavy Dusty Waste Wood Crushing Machine in VN

Wood Pallet Crusher 20t/h Heavy Dusty Waste Wood Crushing Machine in VN


A wood comprehensive crusher, also known as a wood crushing machine, is a machine used in the wood processing industry to crush wood materials into smaller particles. It is a type of wood processing machinery that is primarily used to process waste wood materials, such as wood pallets, furniture waste, and other wood scraps, footpath wood, plank, log and all kinds of non-wood raw materials such as all kinds of bulk straw, cotton wood, reed, etcinto sawdust or wood powder.





The operation principle of the wood pallet crusher also drives the rotor to run at a high speed under the link of the three-belt through the supporting power to crush the materials. The rotor disc of this machine is divided into two parts.
One is hammer type, and the other is blade type. The hammer type rotor is suitable for crushing pallets, building templates, these plate materials with a small number of nails, blade rotationThe sub is suitable for broken branches, sticks and some rounds with larger diameters.



Technical Parameter :

Type

HX4000

HX5000

HX6000

HX7000

HX8000

Roller Spped (r/min)

650

800

800

800

560

Roller Diameter (mm)

800

800

800

1100

1400

Blade/Hammer QTY

4/24

4/28

4/30

4/36

4/46

Main Power (kw)

160

200

250

280

400

Capacity (t/h)

10-15

15-20

20-30

30-50

50-70

Feeding Size (mm)

1260*600

1400*600

1600*600

1600*800

2000*1000

Feeding Method

Chain feeding

Total weight (t)

15

17

21

28

51

Outsize(m)

8*2.45*2.48

8.1*2.35*2.5

9.3*2.8*3

10.8*2.8*3.4

13.3*3.15*3.9

The highligh of pallet wood crushing machine :

Wood pallet crusher is mainly used to grinding waste construction formwork, bamboo plywood, wooden shelves, brackets, wooden packing boxes, wooden pallets, etc. The final product is a small wood chip of about 30mm.


1) Adjustable cutter roller speed: According to the specific requirements of customers, the machine can be refitted and the corresponding parts adjusted to change the cutter roller speed of the machine to meet the different requirements of customers for the output granularity and output.

2) Unique suspension bedknife design: Based on years of manufacturing experience, the original shock-absorbing buffer bedknife device has been applied for patent protection. It greatly reduces the maintenance cost of the whole machine and prolongs the service life of the whole machine.

3) Hydraulic forced feeding: Turn on the oil pump, and the piston of the oil cylinder will expand and contract, so that the swing device will rise or fall, and automatically adapt to the height change of the material. The adaptability of raw materials is wider, and the feeding is more stable and smooth. And has applied for patent protection.

4) Convenient inspection and maintenance: By using the hydraulic system, the machine cover can be opened to check or replace the flying knife, screen, etc. quickly and conveniently.
