10t/h Wood Pallet Crushing Machine Pallet Shredder 1600-600
| Place of Origin | JIangsu China |
|---|---|
| Brand Name | APEX BIOMASS |
| Model Number | DR1600-600/800 |
| Minimum Order Quantity | 1set |
| Price | Negotiable |
| Packaging Details | Plywood cases or iron case is be used . the complete machine is packed by plastic ,all siutable for sea transportation |
| Delivery Time | 25 working days after deposit |
| Payment Terms | T/T, L/C |
| Supply Ability | 15 sets per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Items | Wood Crushing Machine | Name | 10t/h Wood Pallet Crushing Machine Pallet Shredder 1600-600 |
|---|---|---|---|
| Usage | Crushing Pallet ,wood Branch , Straw Etc Into Small Piece | Main Power | 250kw /315kw |
| Crushing Mesh | 50*50mm Or 60*60mm Adjustable | Output | 15-20t/h |
| Total Weight | 22000kgs | Hammer | 36 Pcs |
| Feeding Chain | 6m | Out Feeding | 10m |
| Highlight | 10t/h Wood Pallet Crushing Machine,Pallet Shredder 1600x600,10t/h Wood Pallet Shredder |
||
Product Description
10t/h Wood Pallet Crushing Machine Pallet Shredder 1600-600 A wood pallet shredder , also known as a wood crusher , is a machine used in the wood processing industry to crush wood materials into smaller particles. It is a type of wood processing machinery that is primarily used to process waste wood materials, such as wood pallets, furniture waste, and other wood scraps, footpath wood, plank, log and all kinds of non-wood raw materials such as all kinds of bulk straw, cotton wood,etcinto sawdust or wood powder.Technical Parameter :
Type | DR1260 | DR1400 | DR1600 | DR1600 | DR2000 |
Roller Spped (r/min) | 650 | 800 | 800 | 800 | 560 |
Roller Diameter (mm) | 800 | 800 | 800 | 1100 | 1400 |
Blade/Hammer QTY | 4/24 | 4/28 | 4/30 | 4/36 | 4/46 |
Main Power (kw) | 160 | 200 | 250 | 280 | 400 |
Capacity (t/h) | 10-15 | 15-20 | 20-30 | 30-50 | 50-70 |
Feeding Size (mm) | 1260*600 | 1400*600 | 1600*600 | 1600*800 | 2000*1000 |
Feeding Method | Chain feeding | ||||
Total weight (t) | 15 | 17 | 21 | 28 | 51 |
Outsize(m) | 8*2.45*2.48 | 8.1*2.35*2.5 | 9.3*2.8*3 | 10.8*2.8*3.4 | 13.3*3.15*3.9 |
The highligh of pallet wood crushing machine :Wood pallet crusher is mainly used to grinding waste construction formwork, bamboo plywood, wooden shelves, brackets, wooden packing boxes, wooden pallets, etc. The final product is a small wood chip of about 30mm.1) Adjustable cutter roller speed: According to the specific requirements of customers, the machine can be refitted and the corresponding parts adjusted to change the cutter roller speed of the machine to meet the different requirements of customers for the output granularity and output.2) Unique suspension bedknife design: Based on years of manufacturing experience, the original shock-absorbing buffer bedknife device has been applied for patent protection. It greatly reduces the maintenance cost of the whole machine and prolongs the service life of the whole machine.3) Hydraulic forced feeding: Turn on the oil pump, and the piston of the oil cylinder will expand and contract, so that the swing device will rise or fall, and automatically adapt to the height change of the material. The adaptability of raw materials is wider, and the feeding is more stable and smooth. And has applied for patent protection.4) Convenient inspection and maintenance: By using the hydraulic system, the machine cover can be opened to check or replace the flying knife, screen, etc. quickly and conveniently. Others is wood chipper Recommended Products
