Electric Wooden Pallet Plate Crushing Machine Heavy Duty Wood Crushing Machine

Electric Wooden Pallet Plate Crushing Machine Heavy Duty Crushing Machine for wood

Wood pallet crushin machine is a special equipment of biomass energy power plant for fuel reserve. With the widely raw material it can be crushed, such as all kinds of trees, undersized log, timber cutting residues such as branches, wood processing residues (such as slab, batten, log core, building templates and so on), Also some non-wooden raw materials (such as waste of flax, reed, bamboo, maize straw, cotton stalk, etc.).
 Technical Parameter :

Type

DR1260

DR1400

DR1600

DR1600

DR2000

Roller Spped (r/min)

650

800

800

800

560

Roller Diameter (mm)

800

800

800

1100

1400

Blade/Hammer QTY

4/24

4/28

4/30

4/36

4/46

Main Power (kw)

160

200

250

280

400

Capacity (t/h)

10-15

15-20

20-30

30-50

50-70

Feeding Size (mm)

1260*600

1400*600

1600*600

1600*800

2000*1000

Feeding Method

Chain feeding

Total weight (t)

15

17

21

28

51

Outsize(m)

8*2.45*2.48

8.1*2.35*2.5

9.3*2.8*3

10.8*2.8*3.4

13.3*3.15*3.9

The highligh of pallet wood crushing machine :Wood pallet crusher is mainly used to grinding waste construction formwork, bamboo plywood, wooden shelves, brackets, wooden packing boxes, wooden pallets, etc. The final product is a small wood chip of about 30mm.
1) Adjustable cutter roller speed: According to the specific requirements of customers, the machine can be refitted and the corresponding parts adjusted to change the cutter roller speed of the machine to meet the different requirements of customers for the output granularity and output.

2) Unique suspension bedknife design: Based on years of manufacturing experience, the original shock-absorbing buffer bedknife device has been applied for patent protection. It greatly reduces the maintenance cost of the whole machine and prolongs the service life of the whole machine.
3) Hydraulic forced feeding: Turn on the oil pump, and the piston of the oil cylinder will expand and contract, so that the swing device will rise or fall, and automatically adapt to the height change of the material. The adaptability of raw materials is wider, and the feeding is more stable and smooth. And has applied for patent protection.

4) Convenient inspection and maintenance: By using the hydraulic system, the machine cover can be opened to check or replace the flying knife, screen, etc. quickly and conveniently.








The hammer material is alloy YT18,

We promise:
1.wood chipper completely machine,each key parts we made by cnc milling machine,keep sure the precision.

2.main shaft made by special treatments,longer lifetime.

3.each machine produce based on European standard.

1, How to pay to you ?
T/T inadvance o . We can accept 40% deposit , and balance paid to us before delivery machine to you .
2, How long is the delivery time?
For standard machines, it would be 5-7 days; For non-standard machines and customized machines according to clients specific requirements, it would be 30 days.
3, Do You Arrange Shipment For The Machines?
Yes, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
4,How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, How is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading .
